LA26 (passivo)

The LA26 is a 2-way, full range line array cabinet housing two 6.5" neodymium Planar Diaphragm drivers located in the side walls of the HF Oblate Spheroidal Waveguide, a 2" diaphragm HF neodymium driver and a passive network crossover presenting a nominal input impedance of 16?.
The LF Planar Diaphragm drivers, and its special placement, integrated on the Spheroidal Waveguide, reduces the cavity effect, associated with traditional cone speakers, radiating sound energy smooth and evenly over the entire coverage area. This special arrangement perfectly combines the HF and LF acoustic centers to generate precisely coherent wavefronts uniformly spread in the horizontal plane and precisely coupled in the vertical plane.
The LA26 was designed to be incredibly versatile solving the needs of production companies, rental houses, theaters, houses of worship, working as main system, front fill, side array or as complement of larger-scale LA systems.

Type: 2-way passive line array element
Freq. Resp. (±3dB): 75Hz - 19KHz
Dispersion (HxV): 105ºx12º
Maximum SPL: 127.6dB/130.6dB (Full-Space)
Nominal Impedance: 16º
