M804 DSP
AMPLIFICADOR 4 CANAIS C/ DSP [100V|8ohms]
The M804DSP is a smart full matrix DSP Class D 4-channel amplifier that delivers flexible reliable power output of 4 x 750W in a full rack 2U format, driving both conventional low impedance (2ohms to 16ohms) loudspeakers and high impedance (70V/100V) transformer coupled loudspeakers or any mix of the two. The on board, state-of-the-art, full matrix, DSP engine can be configured to suit a wide range of tasks, without the need for additional equipment, to drive a wide range of loudspeaker systems. Everything you need is right there. The close integration of processing and amplification allows the DSP to monitor and better adapt to amplifier behavior, making dynamics processing far more accurate and effective than that typically achieved with separate components. The active PFC (Power Factor Correction) power supply technology enables universal AC mains operation and delivers consistent, regulated power worldwide.
-
Especificações
Frequência de Resposta: 20Hz - 20kHz (+0 / -0.5dB)
Tecnologia do Amplificador: UMAC Class D - Full Bandwidth PWM Modulator With Ultra-Low Distortion
Nº de Canais de Amplificação: 4 Channels Low Impedance (LoZ) / 2 Channels High Impedance (HiZ)
Potência do Amplificador - Stereo 8Ω: 4 x 400W;
Potência do Amplificador - Stereo 4Ω: 4 x 750W;
Potência do Amplificador - Stereo 2Ω: 4 x 750W;
Potência do Amplificador - Bridge 8Ω: 2 x 1500W;
Potência do Amplificador - Bridge 4Ω: 2 x 1500W;
Potência do Amplificador - 100V: 2 x 1500W;
Potência do Amplificador - 70V: 2 x 1200W;
Saída para Colunas: 2Ω - 16Ω | 100V | 70V
Saída de Zonas: 4-Zones Output
THD+N: <0.05% (20Hz-20kHz, 8Ω load, 3dB below rated power)
SNR (Relação Sinal-Ruído): >108dB (A-weighted, 20Hz-20kHz, 8Ω load)
Tensão à Saída: 85Vp / 170Vpp (unloaded) // Bridged 170Vp / 340Vpp (unloaded)Tecnologia do DSP: Ultimate DSP with WI-FI and Ethernet Connection
Parâmetros Ajustáveis do DSP: Filters: PEQ, FIR, hi/lo-shelving, all-pass, band-pass, hi/lo-pass | Limiters: RMS Voltage, Peak Voltage | GPIO Functions | Routing
Ajuste de Delay: 100ms (34.3m) per Output
Entrada de Energia: AC 100V - 240V 50Hz/60Hz
Consumo de Energia: 700W
Dimensões (LxAxP): 88 x 440 x 332 mm
Fixação: 19" Rack Mount
Peso Líquido: 7.4kg
